Platinum HV 130A OPTO V4

Regular price
Rs. 26,000.00
Sale price
Rs. 26,000.00
Regular price
Earn 13000 Reward Points. Learn More...
Order in the next
to get it by
Details

Description:

One of a Kind Design
The elegant case is made from aluminum alloy material. Each cooling slot and its fin were carefully designed and arranged, and the case has gone through oxidation, coloring and edge-highlighting.

Innovative Heat Dissipation Structure
The innovative "duo" stacking structure allows all components on both sides of the printed circuit boards to quickly conduct heat to the aluminum case.

Excellent Motor Speed Governing
The high performance 32-bit processor, combined with advanced algorithm, makes the motor speed-governing excellent for different conditions. With the adjustable sensitivity of speed-governing, every pilot can find the most suitable settings for his helicopter.

Super Soft Start-Up
The Platinum-HV-130A OPTO makes the motor start extremely soft and avoids tail-drift issues. The start-up time is adjustable within 8 to 25 seconds. This will definitely create a perfect starting point for every flight.

Great Current Endurance
A high-quality and high-voltage MOSFET with a great current endurance guarantees the ESC's safety especially in a extremely high power demanding situation.

Built-in Sparkproof Circuit
Built-in sparkproof circuit effectively eliminates sparks produced at the "powering-on" moment and prolongs the connectors lifespan.


Features:

  • Main Applications: 700-800 Class Helis
  • Governor: Internal
  • Built-in BEC:
  • Continuous Current: 130A
  • Cell Count: 6-14S
  • Case: Aluminum Alloy Shell
  • Programming: LCD Program Box, OTA Programmer, via Separate Program Port
  • Peak Current: 160A
  • Weight: 154g
  • Dimensions: 101x45.5x27mm
  • DEO Technology: Yes
  • Spark-Proof: Yes

Specification:



Type

Brushed/Brushless

High Voltage/Regular

BL

High Voltage

Specifications

Cont./Peak Current


Input Voltage

BEC Output


130A/160A

6-14S LiPo

Switch Mode:5-8V,10A

Wires & Connectors

Input Wires





Output Wires


Input Connectors


Output Connecotors


Red-12AWG-150mm*1/Black-12AWG-150mm*1



Black-12AWG-100mm*3

No

No

Size

101.0x45.5x27.0mm

Weight

169g
