XRotor H120A 18S FOC V1

Regular price
Rs. 12,000.00
Sale price
Rs. 12,000.00
Regular price
Earn 6000 Reward Points. Learn More...
Order in the next
to get it by
Details

Description:

 The XRotor Pro-H120A-18S-FOC-RTF-HW-H-V1 is an intelligent high-voltage ESC designed for drones. It features efficient heat dissipation, vector control (FOC), and various protection mechanisms to ensure flight safety.


Properties

  • Voltage Range: 12-18S (44-78.3V)
  • Continuous Current: 40A (Excellent heat dissipation)
  • Weight: 234g (excluding wires)
  • Product Dimensions: 116mm x 49.4mm x 34.8mm
  • Communication Method: CAN bus
  • Throttle Isolation: Full isolation

Specification:


Input Voltage 12-18s (44-78.3V)
Continuous Current 40A (Good heat dissipation)
Peak Current (3s) 150A
Operating Temperature -20°C to 65°C (Customizable: -40°C to 65°C)
Motor Compatibility Strictly matched with motor parameters
Propeller Positioning None
Protection Class IP55 (Customizable: IP67)
Weight (excluding wires) 234g
Dimensions 116mm x 49.4mm x 34.8mm
Communication Interface CAN bus
Throttle Isolation Fully isolated
PWM Voltage Levels 5V/3.3V
PWM Frequency 50-500Hz
PWM Pulse Width 1100-1940μs
Throttle Calibration Fixed and non-adjustable
Parameter Adjustment Software tuning
Dual Throttle Support Yes
