T Motor Alpha 40A 6S Esc

Rs. 7,125.00
Rs. 7,125.00
Write a Review
Earn 3562 Reward Points. Learn More...

Here is only a suggestion: Reward Points function (demo function). To use real Reward Points, you need a 3rd party Shopify App.

Your items may arrive sooner than the estimated delivery date. Ralph Lauren reserves the right to send packages via other shipping methods based on the shipping destination as long as orders will still arrive within the arrival times outlined on RalphLauren.com.

When you choose the Economy delivery option, packages are delivered Monday through Saturday 8 AM to 4:30 PM. Orders sent by Fast, 2-Business-Day or Next-Day shipping methods are delivered Monday through Friday from 8 AM to 4:30 PM.

We recommend choosing Fast or Next-Day delivery if you are shipping your package to a business address. You will be asked to provide a telephone number on the shipping page of checkout, which is important in the event the courier needs to arrange a delivery time with you.

You will also be asked to provide an email address, to which we will send confirmation that your order was placed.

Add to wishlist Added to wishlist
Order in the next
to get it by
Ask us any Question
Details

Properties:

  1. Model: ALPHA 40A
  2. Brand: T-motor
  3. Voltage: 4-6S ( 18-25.2V)
  4. Current: 40A
  5. Throttle range: 1100-1940μs
  6. Special core program for multi-rotor controller greatly improve throttle response
  7. Power by independence stabilivolt  IC supply microprocessor is with better antijamming performance for stability.

Full- Description

Low noise ALPHA 40A 6S T-motor ESC Featured with low voltage, fast response and linear throttle, Low interference and high efficiency. ALPHA ESC has faster responses with less pulse current and steady startup as compared with traditional square wave driving. This Tiger motor ESC contains over current/Motor Lock-up/short circuit/Low voltage protection. Its Intelligent design enables ALPHA ESC to timely detect parameters as to voltage, current and temperature.

Incorporates IP55 grade to keep water and dust away protect ESC from damage of liquid corrosion as to pesticide for safe operation and 15-20% light-weight design.

Features:

  1. Special core program for multi-rotor controller greatly improve throttle response
  2. Power by independence stabilivolt  IC supply microprocessor is with better antijamming performance for stability
  3. FOC sine driving is adopted for less noise and torque ripple , and better motor and ESC protection
  4. FOC ESCs are with output interface of RPM signal and error status signal
  5. Parameter as to real-time output throttle, RPM, current, capacity temperature and MOSFET temperature are available
  6. 30KHz PWM driving frequency
  7. Online upgrading of ESC firmware is available (Data LINK is needed)

Packages Includes:

  • 1 x T Motor ALPHA 40A 6S ESC
  • 1 x User Manual

Specification:

Brand

T-motor
Model

ALPHA 40A
Item Name

40A 500HZ 4-6S FOC ESC
Voltage

4-6S ( 18-25.2V)
Current

40A
Instantaneous current

（10s):60A
Programming Line

PVC  wiring-30 CORE-3-300MM (Black Red White/JR 3P head)
BEC

NO
Standby power consumption

≤50mA
Throttle range

1100-1940μs
Throttle refresh frequency

500Hz
Throttle response speed

120ms
Recommend  Motor

U3 700KV,U5 400KV,MN5212 340KV,MN4006 380KV,MN501S 360KV,MN501S 300KV,MN7005 230KV
Signal Line

PVC wiring-30 CORE-2-300MM (blank BLACK/JR 3P head)
Color

Silver
Length(mm)

6
Width(mm)

3
Height(mm)

1.5
Weight(g)

56
Shipping Weight 0.178 kg
Shipping Dimensions 16 × 7 × 6 cm
